What are the characteristics of CNC turning process?

Turning is a method of cutting a workpiece on a lathe using the rotation of the workpiece relative to the tool. Turning is the most basic and common cutting method. Most workpieces with revolving surfaces can be processed by turning methods, such as inner and outer cylindrical surfaces, inner and outer conical surfaces, end faces, grooves, threads, and rotary forming surfaces. Common lathes can be divided into horizontal lathes, floor lathes, CNC turned parts, vertical lathes, turret lathes and profiling lathes, most of which are horizontal lathes.

Due to the development of modern science and technology, various high-strength and high-hardness engineering materials are more and more used. Traditional turning technology is difficult or impossible to process some high-strength and high-hardness materials. Hard turning technology makes this possible and yields clear benefits in production.

1. Introduction to the characteristics of turning

(1) High turning efficiency

Turning has higher efficiency than grinding. Turning often adopts large cutting depth and high workpiece speed, and its metal removal rate is usually several times that of grinding. In turning, multiple surfaces can be machined in one clamping, while grinding requires multiple installations, resulting in short auxiliary times and high positional accuracy between machined surfaces.

(2) The equipment input cost is low. When the productivity is the same, the investment of the lathe is obviously better than that of the grinder, and the cost of the auxiliary system is also low. For small batch production, turning does not require special equipment, while large batch processing of high-precision parts requires CNC machine tools with good rigidity, high positioning accuracy and repeatable positioning accuracy.

(3) It is suitable for small batch flexible production requirements. The lathe itself is a flexible processing method with a wide processing range. The lathe is easy to operate and the turning and clamping are fast. Compared with grinding, hard turning can better meet the requirements of flexible production.

(4) Hard turning can make the parts obtain good overall machining accuracy

Most of the heat produced in hard turning is taken away by the cutting oil, and there will be no surface burns and cracks like grinding. position accuracy.

2. Turning tool materials and their selection

(1) Coated carbide cutting tools

Coated carbide cutting tools are coated with one or more layers of coatings with good wear resistance on tough carbide cutting tools. The coating usually plays the following two roles: The much lower thermal conductivity of the matrix and the workpiece material reduces the thermal effect of the tool matrix; on the other hand, it can effectively improve the friction and adhesion of the cutting process and reduce the generation of cutting heat. Compared with cemented carbide cutting tools, coated carbide cutting tools have been greatly improved in terms of strength, hardness and wear resistance.

(2) Ceramic material tool

Ceramic cutting tools have the characteristics of high hardness, high strength, good wear resistance, good chemical stability, good anti-bonding performance, low friction coefficient and low price. In normal use, the durability is extremely high, and the speed can be several times higher than that of cemented carbide. It is especially suitable for high-hardness material processing, finishing and high-speed processing.

(3) Cubic boron nitride tool

The hardness and wear resistance of cubic boron nitride are second only to diamond, and it has excellent high temperature hardness. Compared with ceramic tools, its heat resistance and chemical stability are slightly worse, but its impact strength and crush resistance are better. If you don't want to work at the bottom, want to get rid of the status quo, and want to learn UG programming, you can add QQ group 192963572 to learn CNC machining programming technology. It is widely used in the cutting of hardened steel, pearlitic gray cast iron, chilled cast iron and superalloy, etc. Compared with cemented carbide tools, its cutting speed can even be increased by an order of magnitude.

 3. Selection of cutting oil

(1) The heat resistance of tool steel tools is poor, and the hardness is lost at high temperatures, so cutting oil with good cooling performance, low viscosity and good fluidity is required.

(2) When the high-speed steel tool is used for high-speed rough cutting, the cutting amount is large and a large amount of cutting heat is generated. Cutting oil with good cooling should be used. If high-speed steel tools are used for medium and low-speed finishing, low-viscosity cutting oil is generally used to reduce the frictional adhesion between the tool and the workpiece, inhibit the formation of cutting bumps, and improve machining accuracy.

(3) Cemented carbide tools have higher melting point and hardness, better chemical and thermal stability, and much better cutting and wear resistance than high-speed steel tools. Active sulfur cutting oil can be used in general processing. If it is heavy cutting, the cutting temperature is very high, and the tool is easy to wear very quickly. At this time, inactive vulcanized cutting oil should be used and the flow rate of the cutting oil should be increased to ensure sufficient cooling and lubrication.

(4) Ceramic tools, diamond tools and cubic boron nitride tools all have high hardness and wear resistance, and generally use low-viscosity inactive vulcanized cutting oil during cutting to ensure the surface finish of the workpiece.
